China High Speed PVC Medical Tube Extrusion Line Product, Products
Product Description
Main Technical Specifications
| Model | Processing Tube Diameter Range (mm) | Screw Diameter (mm) | Screw L/D | Main Motor Power (KW) | Production Capacity (Kg/h) |
|---|---|---|---|---|---|
| SXG-65 | 3.0～16.0 | 65 | 28-30 | 30/37 | 55-80 |
| SXG-75 | 4.0～25.0 | 75 | 28-30 | 37/45 | 70-110 |
| SXG-80 | 4.0～25.0 | 80 | 28-30 | 55 | 100-140 |
Production Speed & Diameter Tolerance
| External Diameter (mm) | Production Speed (m/min) | External Diameter Control Tolerance (≤mm) |
|---|---|---|
| ≤3.3 | 150-180 | ±0.02 |
| ≤4.5 | 120-160 | ±0.04 |
| ≤5.3 | 90-150 | ±0.05 |
| ≤7.0 | 65-90 | ±0.06 |
| ≤9.3 | 30-45 | ±0.07 |
| ≤12.0 | 25-40 | ±0.08 |
Cutting Length Accuracy Standards
| Cutting Length | ≤50mm | ≤200mm | ≤500mm | ≤1000mm |
|---|---|---|---|---|
| Cutting Length Accuracy | ±0.5mm | ±1.0mm | ±1.5mm | ±2.0mm |
Frequently Asked Questions (FAQ)
Q: What is the processing tube diameter range for these extrusion machines?
The series covers tube outer diameters from 3.0 mm up to 25.0 mm depending on the selected model (SXG-65 handles 3.0–16.0 mm, while SXG-75 and SXG-80 process 4.0–25.0 mm).
Q: What level of outer diameter tolerance control can be achieved?
Tolerances are strictly held according to tube size, ranging from ultra-precise ±0.02 mm for diameters ≤3.3 mm up to ±0.08 mm for diameters ≤12.0 mm.
Q: What maximum production speeds are achievable?
Production speeds reach up to 150–180 m/min for small tubes (≤3.3 mm) and adjust to optimal rates such as 25–40 m/min for larger diameters (≤12.0 mm).
Q: What is the output capacity among the different models?
Output capacity ranges from 55–80 Kg/h with the SXG-65 model, 70–110 Kg/h on the SXG-75 model, and up to 100–140 Kg/h using the SXG-80 model.
Q: How precise is the inline tube cutting system?
The precision cutter provides accuracy tolerances of ±0.5 mm for short cuts (≤50 mm), extending proportionally to ±2.0 mm for long cuts (≤1000 mm).
